    3d Stone cnc router machine for carving and cutting for marble tombstone

    3d Stone cnc router machine for carving and cutting for marble tombstone

    Machine Features

    1. Adopt Taiwan Hiwin square rails, double-row four colums slide block, high precision, huge bearing capacity, good moving
    stability and tools falling accuracy.

    2. Whole machine welded with thickess steel tubes, not easy to be deformed. Working table backed with steel plate, bearing
    capacity more than1ton

    3. Constant power spindle motor, big cutting intensity and high efficiency.

    4. Dust proof and water proof design protects the transmission components.

    5. Equipped with water tank and automatic water cooling system.
    Specification
    Effective working area
    (X=1300mm)*(Y=2500mm)
    Max Feeding Height
    400mm
    Machine Body
    8mm thickness welded steel tube, cast iron vertical shafts and steel gantry
    Working table
    Aluminum T-slot table with PVC
    Guide rail
    Hiwin linear square guide rail
    Driving method
    Taiwan Gears Rack drive for X Y-axis,lead screw drive for z-axis
    Motor and driver
    Stepper motor(450B) and Leadshine driver(MA860H)
    Spindle Motor
    5.5KW water cooling spindle
    Invert
    Fuling invert
    Spindle collect type
    ER25
    Voltage
    AC220V, 1 phase/3phase, 50-60Hz
    Control system
    Mach 3 USB control system
    Control Cabinet
    Independent
    Other
    Water tank(Bidirectional cooling system)
