Brand Name : | StoneSawMachine.com |
Model Number : | MHLM-3600/4200 |
Certification : | ISO9001 |
Price : | Negotiable |
Payment Terms : | L/C, , T/T |
Supply Ability : | 20 Sets Per Month |
Delivery Time : | 30 days after deposit |
1.It has a compact structure, with mechanical system, hydraulic system and electrical system integrated, high degree of automation, simple operation and easy-to-use feature.
2.The cylindrical guide rail is fully sealed to ensure that the guide rail no pollution and machine has an original lubrication system, so the service life and utilization ratio are effectively increased and maintenance times and costs are reduced. It is a mine quarrying machine with significantly increased comprehensive benefits.
3.Unique cylindrical guide, hydraulic elevator design and super wide chassis, so the structure is more stable and longer useful life.
4.With the super giant saw blades, it can be used for the
processing of ultra-large rocks and blocks to improve out turn
percentage of the mine and make full use of the mineral resource.
5.Disc saw blades cutting is more secure, environmental, lower cost
and more efficient than traditional blasting mining method.
Name | Unit | MCHL-1950/2450-4200 |
Blade Diameter | mm | φ2600*2-φ3600*2-φ4200*2 |
Max cutting depth | mm | 1800 |
Cutting width | mm | 1950-2450 |
Water consumption | m3/h | 5 |
Main Motor power | kw | 55*2 |
Total power | kw | 120 |
Rails Center distance | mm | 1670 |
Overall dimension (L*W*H) | mm | 4000*2150*3500 |
Approximate weight | kg | 10500 |
![]() |
